Connectivity Solutions for the Process Industry

Softing Industrial Data Networks will show smart gateways for multi-protocol process control and a mobile plug & play solution for configuration and maintenance of field devices at the trade show SPS in Nuremberg.

by Andrea Baty

With smart gateways and mobile enterprise solutions, Softing Industrial Data Networks presents itself at the SPS 2019 trade show in Nuremberg as a partner for the process industry on its way to digitalization.
In many process plants control systems of different manufacturers and different generations are in operation due to long running times. The resulting different communication interfaces make it difficult to exchange production and plant data across systems when implementing industry 4.0 applications. Softing’s smartGate product family supports users in integrating disparate protocols, ensures end-to-end digital data exchange and thus creates the prerequisites for greater efficiency and flexibility in production.

Gateways for multi-protocol process control
In addition to the pnGates for PROFINET and the mbGates for Modbus/TCP, Softing will present the new Ethernet/IP to PROFIBUS gateways epGate DP, epGate PA and epGate PB at the fair. This completes the smartGate product family which now supports all Ethernet protocols relevant to the process industry: PROFINET, Ethernet/IP and
Modbus/TCP. The epGates enable the convenient connection of PROFIBUS devices to Ethernet/IP controllers, e.g. from Rockwell, Schneider Electric or Emerson. There is also news for the Modbus/TCP to PROFIBUS gateways. At the fair, version 1.20 of mbGate DP, mbGate PA and mbGate PB will be on display, which has been extended by the “High Availibility” option.
It allows the operation of a redundant system with two Modbus/TCP controllers and two Modbus/TCP gateways.
In this way, system availability is ensured even in the event of a connection failure. The mbGates enable the direct integration of PROFIBUS PA and DP segments into Modbus/TCP systems. They act as Modbus server and PROFIBUS master and connect up to four PROFIBUS PA segments as well as one DP segment with Modbus TCP.
All gateways allow use of the existing power supply in technology upgrade projects, which significantly reduces engineering costs. Configuration and asset management can be carried out using industry-standard tools.

The mbGates enable the direct integration
of PROFIBUS PA and DP segments into Modbus/TCP systems. They act as Modbus server and PROFIBUS master and connect up to four PROFIBUS PA segments as well as one DP segment with Modbus TCP.
All gateways allow use of the existing power supply in technology upgrade projects, which significantly reduces engineering costs. Configuration and asset management can be carried out using industry-standard tools.

Mobile Enterprise Solutions
Modern process plants require digital, mobile, networked and standardized solutions that make data from plants, machines and field devices easily accessible and streamline maintenance procedures for configuring, commissioning and troubleshooting the devices. This is where Softing’s mobile interface mobiLink comes in.
It provides access to the three most important communication protocols in process automation – HART, FOUNDATION Fieldbus and Profibus PA – via a single interface. The connection to the mobile device can be made via USB or Bluetooth. With the newly available FDI Communication Server it is now possible to use mobiLink with FDI applications.
The DevCom app for Android or Windows adds an application for device parameterization to the offering.
A new version – mobiLink Power – will be available at the beginning of 2020. This will allow field devices to be supplied with power, which is obtained via the USB port. An external power supply for the field devices is no longer necessary.
