Ultra-precise motion control for digital pathology applications

ALIO is at the forefront of motion control solutions for digital pathology, a growing field that places stringent requirements on accuracy, of nanometer-level, to ensure high quality scans at high speed.

ALIO Industries has a 20-year history working at the vanguard of nanometer-level precision motion control; the company is at the vanguard of a revolution that is taking place in the world of in-vitro medical diagnostics, namely digital pathology where the demands on the accuracy of motion control solutions are particularly severe. Digital pathology includes the acquisition, management, sharing and interpretation of pathology information – including slides and data – in a digital environment. Digital slides are created when glass slides are captured with a scanning device, to provide a high-resolution image that can be viewed on a computer screen or mobile device. Digital pathology is increasingly used by biopharmaceutical companies and clinical research organizations (CROs) to help to streamline drug development processes in discovery, pre-clinical, and clinical trials. It is also used for quantitative analysis of emerging companion diagnostics and novel theranostics (a combination of therapeutics and diagnostics). This opportunity has become especially relevant with the use of assays which are difficult to discern with the human eye, such as markers which exhibit diffuse staining characteristics across multiple cellular compartments of which, for example, only one may be clinically relevant. The increasing complexity of such assays is driving the development of digital pathology solutions with advanced high-throughput image capture (brightfield, fluorescent or multispectral) coupled with pattern recognition to morphologically identify relevant tissue types and individual cellular compartments followed by the ability to quantify intensity of staining.

Nanometer-level precision and high speed are the essential requirements

Digital pathology – which has the potential to enhance the efficiency of pathology for both medical practitioners and patients – requires top-end nanometer-level precise motion control solutions to facilitate high-speed and high-quality scanning/imaging while maintaining a small footprint so as not to take up too much space in a lab/clinical environment. In the area of digital pathology, the xyz motion control stage moves the slides that are to be scanned underneath a fixed microscope or camera which captures images of the slides. The key is image capture at a high rate of speed with absolute focus on precision, which requires that the chosen motion control solution must combine smoothness (meaning highest possible image resolution), flatness (controlling the z-axis meaning maintenance of focus), and straightness (reducing overlap between scanning “passes” and increasing throughput).

Customized motion solutions for a top-level application

The motion control solutions that are required in digital pathology applications cannot be bought off-the-shelf. Attention must be placed on every component that is used in the custom stage to be used, and as such ALIO is a preferred supplier for a number of reasons, not least the fact that it is used to working with life science applications. ALIO has a very advanced machine shop, using state-of-the-art technologies in controlled environments to ensure optimised motion control products are manufactured. In addition, an in-house metrology department uses best-in-class measurement tools to allow us to prove complete adherence to design intent. “In a world where nanometers are the focus – CEO and Founder of ALIO Industries says – precise measurement and validation is key to successful motion control solutions, and so ALIO has 100%-part verification.” ALIO’s stages are used in digital pathology applications, where the requirement for image stitching of the scanned data is so vital. ALIO stages are characterized by the ability to move straighter than any other stages in industry, and therefore the resolution and accuracy of the data captured is superior, meaning reduced reliance on software to interpret and ‘guess’ what data readings are showing. ALIO provides completely customised motion control solutions and so is able to work with digital pathology solution providers early in the design stage of process development to ensure the most efficient motion control solution possible.
